Conector circular TE Connectivity Conector hembra Subminiature serie TRIAD 01 de 4 vías Hembra, Cable, IP65
Documentos Técnicos
Especificaciones
Brand
TE ConnectivityNumber of Contacts
4
Product Type
Circular Connector
Mount Type
Cable
Connector Size
Subminiature
Current
3A
Plug/Socket
Socket
Contact Gender
Female
IP Rating
IP65
Series
TRIAD 01
Orientation
Straight
Mating Type
Cable
Minimum Operating Temperature
-40°C
Termination Type
Solder
Maximum Operating Temperature
85°C
Housing Material
Polybutylene Terephthalate
Standards/Approvals
No
Contact Plating
Nickel
Contact Material
Copper Zinc Alloy
País de Origen
Germany
Datos del producto
Conectores macho y hembra y latiguillos
Cable mount plugs and sockets will mate each other to make in-line connections as well as with panel and PCB mount types. They are supplied complete with assembly tool and instructions. Alternatively, cable assemblies are available also that have 3-metre cable lengths and are pre-wired and moulded onto cable plugs. The body shell is the same size for all number of ways.
Longitud de conector macho de 40 mm, diámetro exterior de 12 mm
Longitud de conector hembra de 38 mm, diámetro exterior de 12 mm
Triad 01 - Metal
TRIAD 01 is a screw-locking subminiature connector possessing excellent shielding properties that meet EMC requirements.,TRIAD 01 is also water and gas tight according to IP65. The range is 100% compatible with the Binder 711//712 ranges.
Volver a intentar más tarde
$ 74.513
$ 74.513 Each (Sin IVA)
$ 88.670
$ 88.670 Each (IVA Inc.)
1
$ 74.513
$ 74.513 Each (Sin IVA)
$ 88.670
$ 88.670 Each (IVA Inc.)
Volver a intentar más tarde
1
| Cantidad | Precio Unitario sin IVA |
|---|---|
| 1 - 9 | $ 74.513 |
| 10+ | $ 67.064 |
